Qnap TS-464U-RP-8G 4-Bay NAS 2.5GbE, 4K HDMI PCIe Gen 3 Rackmount

Powered by an Intel® Celeron® N5105/N5095 quad-core processor (burst up to 2.9GHz), the TS-464U-RP features two 2.5GbE RJ45 ports and Port Trunking for up to 5Gbps combined bandwidth. The built-in 4K HDMI output allows for multimedia and virtual machine display. With a PCIe Gen 3 slot, the TS-464U-RP provides flexibility in extending NAS functionality, allowing you to install various cards: a 10GbE/5GbE network card, QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition. The TS-464U-RP also supports AES 256-bit encryption to ensure the confidentiality of sensitive business data without affecting system performance. The TS-464U-RP also features a redundant power supply to ensure maximum system uptime.

• 2.5GbE connectivity

  Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports.

• PCIe expandability

  Install a PCIe Gen3 x2 card to expand the core functionality of the TS-464U-RP, including a Multi-Gig 10GbE/5GbE/2.5GbE network card, a QM2 card, or a USB 3.2 Gen 2 (10Gbps) card.

• Snapshots

  Protect your files and data from accidental deletion and malware attacks with snapshots that fully record the system status and data.

• License-free virtualized environment

  Host multiple containerized apps to run a wide range of applications and services.

• Drives Auto-Tiering

  Qtier™ auto-tiering technology and SSD caching enable constant storage optimization.

• Flexible expansion

  Scale your storage capacity to fit growing data needs by connecting QNAP's expansion units.

Quad-core high performance and up to 16GB RAM

The TS-464U-RP is powered by an Intel Celeron N5105 / N5095 quad-core processor and supports up to 16 GB DDR4 memory, two 2.5GbE ports and SATA 6 Gb/s drives. The integrated Intel® AES-NI encryption engine also helps protect confidential data without impacting system performance.

Streamline large file transfers and video editing with 2.5GbE

The TS-464U-RP comes with two 2.5GbE RJ45 (2.5G/1G/100M) LAN ports that allow you to use existing CAT5e cables to upgrade network speeds from 1 Gigabit to 2.5 Gigabit. The dual 2.5GbE ports also support Port Trunking for up to 5 Gbps transmission speeds, improving the efficiency of bandwidth-hungry business applications such as large file transfers, fast backup/restore, and multimedia transfer & editing.

• Product Type: SAN/NAS Storage System
• Standard Memory: 8 GB
• Operating System: QTS 5.0.1
• Form Factor: Rack-mountable
• Processor Speed: 2 GHz
• Processor Type: Celeron
• RAID Levels: 0, 1, 5, 6, 10, JBOD
• Controller Type: Serial ATA/600
• Rack Height: 1U
• Brand Name: QNAP
• Expansion Slot Type: PCI Express 3.0 x2
• Flash Memory Capacity: 4 GB
• Processor Manufacturer: Intel
• RAID Supported: Yes
• Ethernet Technology: 2.5 Gigabit Ethernet
• Number of Total Expansion Bays: 4
• Number of Total Expansion Slots: 1
• HDMI: Yes
• Network (RJ-45): Yes
• Maximum Power Supply Wattage: 250 W
• Total Number of USB Ports: 4
• Number of Hard Drives Supported: 4
• Number of Hard Drives Installed: 0
• RAID Levels: 0, 1, 5, 6, 10, JBOD
• Controller Type: Serial ATA/600
• RAID Supported: Yes
• Product Type: SAN/NAS Storage System
• Manufacturer Part Number: TS-464U-RP-8G
• Manufacturer Website Address: http://www.qnap.com
• Manufacturer: QNAP Systems
• Product Model: TS-464U-RP-8G
• Product Name: TS-464U-RP-8G SAN/NAS Storage System
• Brand Name: QNAP
• Expansion Slot Type: PCI Express 3.0 x2
• Number of Total Expansion Bays: 4
• "Number of 2.5""/3.5"" Bays": 4
• Total Number of Expansion Slots: 1.0
• HDMI: Yes
• Number of Network (RJ-45) Ports: 2
• Network (RJ-45): Yes
• Total Number of USB Ports: 4
• Number of USB 2.0 Ports: 2
• Number of USB 3.2 Gen 2 Ports: 2
• Protocols: CIFS/SMB
• Protocols: DDNS
• Protocols: DHCP
• Protocols: FTP
• Protocols: FTPS
• Protocols: FXP
• Protocols: HTTP
• Protocols: HTTPS
• Protocols: IPSec
• Protocols: IPv4
• Protocols: TLS
• Protocols: IPv6
• Protocols: SNMPv2
• Protocols: SFTP
• Protocols: PPTP
• Protocols: NFS
• Protocols: LDAP
• Protocols: AFP
• Protocols: SSH
• Protocols: SSL
• Protocols: Telnet
• Protocols: TFTP
• Protocols: iSCSI
• Protocols: WEBDAV
• Protocols: L2TP
• Standard Memory: 8 GB
• Memory Technology: DDR4 SDRAM
• Ethernet Technology: 2.5 Gigabit Ethernet
• Weight (Approximate): 8.12 kg
• Form Factor: Rack-mountable
• Rack Height: 1U
• Height: 43.2 mm
• Width: 430 mm
• Depth: 479 mm
• Number of Power Supplies Installed: 2
• Redundant Power Supply: Yes
• Maximum Power Supply Wattage: 250 W
• Processor Speed: 2 GHz
• Processor Type: Celeron
• Processor Core: Quad-core (4 Core)
• Processor Manufacturer: Intel
• Operating System: QTS 5.0.1
• Flash Memory Capacity: 4 GB
• Number of Hard Drives Supported: 4
• Number of Hard Drives Installed: 0
• Number of Solid State Drive Supported: 4
• Number of Solid State Drive Installed: 0
