One Cable. Connectivity for Your World.

Through a single cable the OWC Thunderbolt 3 Dock brings an unprecedented combination of ports, convenience, and power to your Thunderbolt 3 equipped Windows PC or Mac. Bring functionality back to your notebook. Quickly access all of the displays and peripherals at your desk while minimizing desk clutter. Charge your computer and all of your mobile devices simultaneously. Connect and make any shared workspace feel like home.

Welcome to your new world of connectivity.

Connect. Work. Disconnect. Go.

The days of only working at your desk are gone. We're always on the move bouncing between our desks, meetings, and couches - often in a hurry. With a single connection to your notebook computer, the OWC Thunderbolt 3 Dock makes coming back to your desk to work and leaving your desk to run to a meeting, a much quicker endeavor.

The right ports, right where you need them

Our engineers evaluated thousands of possibilities in discovering the optimal port configuration for nearly any environment. With its 14 ports of connectivity thoughtfully placed, the OWC Thunderbolt 3 Dock delivers convenience while keeping desktops clutter-free. The docking station's front is designed for the easy connection of your portable devices, headphones and media cards, while the rear features a multitude of ports for your static devices so cables stay out of sight.

(1) USB-C (USB 3.1 Gen 2) port
(1) USB-A (USB 3.1 Gen 1) port
(1) SD card reader slot
(1) microSD card reader slot
(1) Combo in/out audio jack

(2) Thunderbolt 3 (USB-C) ports
(1) Mini DisplayPort 1.2
(4) USB-A (USB 3.1 Gen 1) ports
(1) Gigabit Ethernet
(1) S/PDIF digital audio output jack

Power to the ports.

Leave your power adapters in your bag! The OWC Thunderbolt 3 Dock provides 85W of power to your computer via the Thunderbolt 3 connection and has multiple high-power USB ports to charge your mobile devices. The days of searching for your power adapter are officially over.

Thoughtful design - inside and out

Carefully chosen ports and functionality bring a new world of possibilities to your desktop, but we've also worked to ensure the OWC Thunderbolt 3 Dock is built to last. A seamless design wrapped in a single piece of aluminum brings a rugged exterior to endure your day-to-day, while maintaining a stylish design that complements any workspace.

Disconnect in One Click

OWC Dock Ejector software safely disconnects drives in a single click. Designed by OWC hardware and software engineers, Dock Ejector ensures all data is written before disconnection, saving time and protecting against data loss. Use it to move quickly between workstations and get the most out of your OWC Dock. Learn More and Download the OWC Dock Ejector Now.

Thunderbolt 2/Thunderbolt compatibility requires a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 (mDP) adapter and a Thunderbolt 2 cable. This configuration provides data transfer at Thunderbolt 2 speeds (up to 20Gb/s) but does not support notebook charging.

Product Specifications:

Host Interface: Thunderbolt 3
Product Type: Docking Station
Device Supported: Notebook
Limited Warranty: 2 Year
Connectivity Technology: Wired
Brand Name: OWC
Ethernet Technology: Gigabit Ethernet
Network (RJ-45): Yes
Maximum Power Supply Wattage: 85 W
Total Number of USB Ports: 6
Thunderbolt: Yes
Mini DisplayPort: Yes
USB Type-C: Yes
Product Color: Black
Product Color: Space Gray
Product Type: Docking Station
Manufacturer Part Number: OWCTB3DK14PSG
Manufacturer Website Address: http://www.macsales.com
Packaged Quantity: 1
Manufacturer: Other World Computing
Product Name: Thunderbolt 3 Dock
Brand Name: OWC
(1) USB-C (USB 3.1 Gen 2) port
(1) USB-A (USB 3.1 Gen 1) port
(1) SD card reader slot
(1) microSD card reader slot
(1) Combo in/out audio jack

(2) Thunderbolt 3 (USB-C) ports
(1) Mini DisplayPort 1.2
(4) USB-A (USB 3.1 Gen 1) ports
(1) Gigabit Ethernet
(1) S/PDIF digital audio output jack

Power to the ports.

Thoughtful design - inside and out

Disconnect in One Click

Host Interface: Thunderbolt 3

Network (RJ-45): Yes

Total Number of USB Ports: 6

Thunderbolt: Yes

S/PDIF Out: Yes

Headphone/Microphone Combo Port: Yes

Mini DisplayPort: Yes

USB Type-C: Yes

USB Type-C Detail: (2) Thunderbolt 3 (USB-C) Ports, (1) USB-C (USB 3.1 Gen 2) port

Number of Mini DisplayPort: 1

Number of USB Type-C Ports: 1

Number of USB Type-A Ports: 5

Number of USB 3.1 Gen 1 Type-A Ports: 5

USB Type-A: Yes

Package Contents:

Thunderbolt 3 Dock

1 x 0.5 m (18 inches) Thunderbolt 3 Cable (5A)

1 x External Power Supply and Power Cable

1 x Quick Start Guide

1 x Dock Ejector Software

Compatibility:

Compatible with Intel / AMD based desktop/laptop PCs with built-in Thunderbolt 3 Ports

Apple Products:

Mac Pro Rack (Early 2020)
Mac Pro (Late 2019)
Mac mini (Late 2020)
iMac Pro (27-inch Late 2017)
iMac w/Retina 4.5K display (24-inch Mid 2021)
iMac w/Retina 5K display (27-inch Mid 2020)
iMac w/Retina 5K display (27-inch Early 2019)
iMac w/Retina 4K display (21.5-inch Early 2019)
iMac w/Retina 5K display (27-inch Mid 2017)
iMac w/Retina 4K display (21.5-inch Mid 2017)
iMac (21.5-inch Mid 2017)
MacBook Pro (13-inch Touch Late 2020)
MacBook Pro (13-inch Touch Mid 2020)
MacBook Pro (13-inch Touch Mid 2020)
MacBook Pro (16-inch Touch Mid 2019)
MacBook Pro (15-inch Touch Mid 2019)
MacBook Pro (13-inch Touch Mid 2019)
MacBook Pro (13-inch Touch Mid 2019)
MacBook Pro (15-inch Touch Mid 2018)
MacBook Pro (13-inch Touch Mid 2018)
MacBook Pro (15-inch Touch Mid 2017)
MacBook Pro (13-inch Touch Mid 2017)
MacBook Pro (13-inch Retina display Mid 2017)
MacBook Pro (15-inch Touch Late 2016)
MacBook Pro (13-inch Touch Late 2016)
MacBook Pro (13-inch Retina display Late 2016)
MacBook Air (13-inch Late 2020)
MacBook Air (13-inch Early 2020)
MacBook Air (13-inch Mid 2019)
MacBook Air (13-inch Late 2018)

Mac OS Compatibility:

macOS 11.x Big Sur
macOS 10.15 Catalina
macOS 10.14 Mojave
macOS 10.13 High Sierra
macOS 10.12 Sierra

PC OS Compatibility:

Windows 10 32-bit Edition
Windows 10 64-bit Edition
Windows Server 2016

Environmentally Friendly: Yes

Brand Compatibility: Apple

Kensington Security Slot: No

Ethernet Technology: Gigabit Ethernet

Weight (Approximate): 500 g

Length: 89 mm

Height: 25 mm

Width: 230 mm

Product Color: Space Gray

Product Color: Black

Maximum Power Supply Wattage: 85 W

Operating System Supported: macOS

Operating System Supported: Windows

Device Supported: Notebook

Connectivity Technology: Wired

Memory Card Supported: SD

Memory Card Supported: microSD

Memory Card Reader: Yes

Number of Displays Supported: 2

Supported Resolutions: 3840 x 2160

Supported Resolutions: 5120 x 2880

Screen Mode Supported: 4K

Screen Mode Supported: 5K
